Material: Low carbon steel.
Protective Finish: Zinc plated & Passivated
Based upon Din Standard 71752IC & ICL
Clevises are machined for precision, and available in both standard and long series. Cross hole deburred on all four faces to facilitate assembly of clevis pin.
All IC & CL Clevises are compatible with SPI & SPIL Spring Pins or CPI Clevis Pins.
Metric sizes of this range are also available.
For Stainless Steel Clevis Assemblies or left hand threads and non-standard Clevises. Please contact
31125, 202941, 213498, 31800, 202942, 213649, 215146, 29025, 202944, 202782, 42212, 215149, 202778, 45985, 215151, 29132-001, 215145, 38820, 215147, 43034, 215148
We offer a wide range of configurable options to match your exact setup:
Thread type & length
Custom male or female thread types (metric, UNC, UNF, etc.)
Extended or shortened threaded shank for deeper adjustment range.
Material & finish
Stainless steel for marine or corrosive environments.
Aluminum for lightweight applications.
Coatings like zinc plating, powder coat, or anodizing for extra durability.
Cable integration
Swaged or crimped connections for permanent attachment.
Detachable clevis with set-screws or clamps for field replacement.
We work with you from concept to completion, helping you replace legacy parts or develop custom systems.
Our engineers provide CAD-based configuration, prototyping, and testing to ensure your cable works perfectly the first time. We also offer push-and-pull testing as standard, with lifecycle testing available on request. For urgent projects, same-day or next-day turnaround can be arranged to keep your production schedules moving.
Services available:
CAD design, prototyping, push-and-pull testing, lifecycle testing (on request), plus same-day and next-day turnaround to support urgent marine, industrial, or specialist engineering projects.
CAD design,
Prototyping,
Push-and-pull testing,
Lifecycle testing (on request),
Same-day and next-day turnaround to support urgent marine, industrial, or specialist engineering projects.
